Galvanised Steel 6mm Narrow fence bracket
PRODUCT DESCRIPTION
Galvanized Fence Bracket Join Timber And Steel Fence Posts To Retaining Wall Posts
The Arrow style Fence brackets / Fence cleats are specifically designed to join timber and steel fence posts to Retaining Wall Posts and are best suited for our UC100 galvanised steel channel posts to cover most of your requirements when adding a fence to your retaining wall.
Features
* Can be welded or bolted onto the steel channels
* Heavy-duty 6mm thickness
* Sleeper wall steel in stock with holes already drilled to suit brackets
* Suits H-Channel Posts, C-Channel Posts, 90° Right Angle Posts, and 45° Corner Channel Posts
PARAMETERS
|
Shape |
Surface |
Dimensions |
Weight |
|
Arrow Style |
HDG |
580 × 100 × 3 mm |
0.95 kg/pcs |
|
Arrow Style |
HDG |
580 × 100 × 6 mm |
1.9kg/pcs |
DETAILS IMAGES
Arrow Steel Fence Bracket / Fence Cleats for Retaining Walls Posts
3mm - used for Colorbond Fences
6mm - used for Timber Fences The galvanized fence bracket allows your fence to bolt directly on top of your retaining wall
RELATED PRODUCTS
Straight Steel Fence Bracket
Arrow Offset Steel Fence Bracket
Straight Offset Steel Fence Bracket
The Xinhuiying Steel Retaining Wall Post System provides an “all-in-one solution.” Made with heavy-duty steel, Xinhuiying Steel Retaining Wall Posts are fully hot-dip galvanised for corrosion protection in accordance with AS/NZS4680:2006.
A range of lengths is available in two depth sizes:
100mm Series to suit 75mm Sleepers
150mm Series to suit 100mm Sleepers.
The 6mm fence bracket attaches using two pre-drilled M12 holes located in both the bracket and corresponding 100UC or 100PFC, and can accommodate timber or metal fence connections for easy installation, saving time and money.
